An Abbreviated Pickle History

Catching Up

Let’s do a little review, shall we? The past years have been typical in their atypicality; no two years quite the same.

2017
  • Our Engine Control Unit, a Pectel T6-2000, is used for the first time.
  • The Hayabusa engine has been tuned to 400+ hp on an engine dyno. Our confidence is high!
  • But at Bonneville, it’s way too rich for some reason.  Max speed of 142mph or so.  We have no data to know what we might change.
2018
2019
  • Pickle rested. And, as was revealed later, rusted.
2020
  • Team chatter started on “Raising the record on Blown Gas Coupe (/BGC)”; the current 176mph  seemed like an easy pear to pick (given that nearly the same motor+car had gone over 200mph).
  • But things had changed… the turbo shaft was not spinning freely, the brakes weren’t spinning at all, and the motor’d become hard to start. We made a whole routine about how much throttle, when to switch the fuel pump on, how high the battery voltage needed to be… nothing really helped.
  • At Speed Week, we had slow runs, low compression, and weak speeds. Without the powerful turbo overcoming the lack of compression there’d have been nuttin’.
2021
  • The lack of valve clearance prompted us to remove the cylinder head and have it rebuilt. The compression numbers improved, but the hard starting remained.
  • We tried tweaking the starting fueling, tweaking ignition timing, different routines… but no real improvement.
  • When Pickle was running, it didn’t seem to be making much power. The boost level was low… for some reason.
  • We threw a chain early and busted the water pump. Our confidence in the drivetrain was pretty low.
2022
  • In the off season, we were determined to fix the issues.  We diagnosed and corrected the hard starting; we machined a new, solid core, front axle and mounted it in a strengthened chassis; we had another dyno session with an expert Pectel tuner.
  • But Speed Week was a total rain out… we never even left the Red Garter parking lot. World Finals, also rained out.
2023
  • Gotta be our year! We were ready in 2022, and we’ve only improved things in the off season
  • Pickle starts very easily. Compression is good, and it seems like our boost could be back
  • But Rain! Not enough to cancel the meet, but it forced everyone to a single short course.
  • Chances that we could challenge the existing record are poor on a short course
  • Ran out of gas trying to make two runs on one tank of fuel.
  • We ran around 160mph, best of 164mph, spun the car at around 160mph, and still managed to break a chain
  • The high-tech ‘clamping collars’ that mount the axle sprocket seemed to be … moving sideways?

2024 On The Salt: Pickle Shows Up, and Shows Off

If you need a refresher, see: An Abbreviated Pickle History



In late 2023, we said, “Let’s be ready for Speedweek ’24”

  • Improvements: We abandoned the fancy split-collar axle sprocket mounts and cut a keyway in the solid front axle instead, changed from a set of independent GoPros to a simpler 4-camera setup, made the steering wheel removable, and did some tiny tuning to avoid loading up during our long warm-up idling
  • Maintenance: Pickle got some body ‘freshening’ and paint, a new ECU Battery, an automatic thermo-switch, and some new brake lines
  • Safety: belts, helmets, fire extinguishers, clothing… all items are up-to-date and certified
  • Schedule: Our list was down to the ‘nice to haves’ by four weeks out — probably a record for our deadline performance

This Is The (Speed)Week That Was

It was so very, very, very hot. 110+ hot. Other teams’ engines–that had never been troublesome before–were melting during their runs. We were melting ourselves; the staging lines were desert-caravan long. A partial cause of the long lines was that recent years had seen bad salt conditions, so this year brought out all the pent-up racers.

Sat Aug 3 – At 3:10pm, there were still 55 vehicles in line for the short course. We did not join the queue that day, and instead went looking for lodging. Wendover was FULL. Found a hotel in Wells, and made the 60 mile transit that night and the following morning.

Sun Aug 4 – Final prep, got in line. The short course was cursed with Instagram influencers, 50mph mopeds, rookies, and folks whose cars and/or drivers weren’t yet qualified for the long course. It moved at the speed of a glacier. We waited about 5 hours, didn’t reach the starting line, and  parked on the side of the lane in a queue for the following morning.

Mon Aug 5 – Next morning, after the Record Runs, we got our first run at 8:58am. Only three miles on the short course, and we ran 178mph in Mile 3, but missed the 175mph “in the quarter” which could have promoted us the to the long course. Questions about the car’s performance and checking the chain took the rest of the day. We planned to get in line early for Tuesday.

Tue Aug 6 – Made a run at 12:24pm, and qualified for a record (back-up) run with a 192mph in Mile 3. Okay! That’d be more than 12mph over the record if we could back it up. We took the record-run-same-day-at-4pm option – but when we reached the head of the line, the car would not start. We pushed it off, and the Hayabusa roared … for a second or two, then Pickle coasted off the course before the first quarter-mile marker.

Back in the pits, we started diagnosis, but turned up nothing conclusive. Review of data later that evening showed a curious trace on the VBAT value, which suggested that the Pectel was powered-on continuously — but the injectors and coils were not.

Wed Aug 7 – We hit the salt early to correct the non-starting. We found a broken wire, probably caused the previous afternoon in impound, as we were draining the intercooler.  The long (nightmare-long) waits in the staging lanes, made more hellish by the heat, convinced us to switch drivers and we moved to the long course.

The long course is run by both fast cars (less time on course) and by experienced teams (less time spent at the starting line). It moved more quickly than the short course line, and we made a run at 13:26pm. Over 190mph in both Mile 3 & Mile 4, hellya; but later we were disqualified and kicked out of Impound for a procedural error during the run.

In the pits, we found a split CV boot and … we were hearing some CV Joint noises. It’s probably worth saying that the drive chain, so far, was looking very good after every run.

Thu Aug 8 – Some shrinkage of the staging lines. On the long course, we made a run at 10:03am, and again qualified for a back-up (record) run by going  over 194mph in Mile 3 and Mile 4.

We took the record-run-the-same-day-at-4pm option, and pushed off the starting line at 16:47pm. But Pickle broke the chain almost immediately off the line, and again we failed to “back up the qualifier”.

In the pits, we found a tooth broken off the primary sprocket. That’s new; the primary sprocket is hardened steel, and has never caused a problem before. But our best guess is that the loose tooth got lodged in the next sprocket valley and that popped the chain. We had no spare primary sprocket, and we had a bit of damage to the clutch pushrod, so our week was finished.

Our score was 3/6: three times in Impound, but three failures to complete the backup run.  🙁

We were encouraged that we had multiple runs over 190mph, but still troubled by the chain, CV joints, and the boost control system. We found the boost knob at 26 clicks out from minimum, while our spec said it should be 10 clicks out: how…?. Our MAP sensor recordings showed good peaks in the lower gears, but when Pickle settled in for a long pull, the graph came down then looked like it was ‘fluttering’ in a narrow range. We surmised the fluttering was  the action of the wastegate… but why the boost control system allows larger peaks earlier is a head-scratcher.

Pickle went into the trailer and we drove home.

Just In Case We’re Going To World Finals

Though our SpeedWeek performance was not satisfying, the Salt was pretty good. We started watching the weather for the late September/early October meet “World Finals”. What must we do to improve our chances in the few weeks we have?

  • More attention and more spares paid to our chains and sprockets; talk of changing them every two runs?
  • Got a stack of new-to-us CV joints, and assembled both axles with good joints, new boots, and new grease
  • We disassembled the wastegate and manual boost controller, looking for answers on the inconsistent boost.
  • In the garage, we fixed a host of boost leaks, including a MAP sensor that had cracked its cover and failed
  • In a remarkable flurry of speed-fabrication, we built “hub adapters” for the ’59 SAAB to connect it to a modern dyno
  • The dyno showed that a prime cause of boost unpredictability was our “bleed type” manual boost controller. It also showed that the Hayabusa motor could still produce serious power. We fitted a dead-simple manual boost controller and dialed in a ‘safe’ level
  • The tuner on-site at the dyno opined that our on-power fueling might be way too rich, and costing some power… but we deferred  further tuning for a future day.









World Finals ’24

Surprising even ourselves, we were ready again, with no known issues. We expected to make a couple of 190mph runs right off the bat.

Sat – Made a run at 5pm, barely over 180mph. We qualified, but what happened to the 195s? Our RK chain looked like raw bread dough. We got no logging out of the Pectel (probably from tutor error during a previous “let’s write new log settings” session), but the databox has its own MAP, and that MAP sensor says boost is low so we gave the manual boost controller 2 1/2 turns toward the positive. And fitted a new chain, naturally.

Sun – What do you know? The car (which is the current and previous record holder in BGC) was disqualified in impound. The rule cited was “the radiator cannot be blocked before or behind”… and that rule, ill-suited as it is to a car whose factory radiator location is behind the engine, was now held to bar any record attempts on the Blown Gas Coupe record in its current configuration.

Okay; we’d brought the body parts required to make the Pickle into a Blown Gas Altered Coupe, and we installed them. Got through the (single) staging line at past 5pm… it would be a short impound session if we qualified, but the whole meet is short, so let’s run. Push-off at 17:37.

Brandon took the Pickle faster than she’d ever run before. Holey moley fast, boost looked strange but the fueling was spot on. The VX3 chain was little loose, but that was the chain we used for multiple runs at SpeedWeek, and besides: we had no time to change it.

The ‘strange boost’ we traced to another blown apart MAP sensor (insert complaint about globalization and offshore manufacturing) but there was a silver lining. The Pectel was fueling as if there were 10-12 PSI of boost, but there were actually 26-29 PSI of boost: and the fueling was perfect. Well: a demonstration will convince even skeptics, and we opted to set the high-boost fueling as the accident had instructed us.

Mon – Impound: we wanted to install our spare MAP sensor, but the harness connector was slightly different, and we had no time to hook it up. The databox wouldn’t know what the manifold pressure was in this upcoming Record run. That’s okay, because the Pectel MAP was still good, and that’s the one that gets used to set fueling. The manifold pressure had been a little high on the qualifier, so for “motor safety”, we took a half-a-turn out of the boost control knob.   Heh.

Pickle to Team: I’ll show you some boost, folks.

Somewhere mid-run the boost control hose separated from the wastegate, and thus there was effectively no boost control. The turbo, unregulated, took manifold pressure off the chart. This let the Hayabusa reach near the programmed maximum RPM in fourth, fifth, and six gears (a first for us on the Salt).  Then, at redline in top gear and at never-before-seen levels of power, at 220 mph, the left outer CV joint “stripped out”.

At that speed, something like 500 horsepower is required just to maintain velocity; it takes 500 horsepower delivered through two front tires. When the left side axle could impart no power to the left side wheel, the right side wheel got, suddenly, twice the power it had a moment before. That is, when the left side tire couldn’t deliver power anymore, all the power spilled out the right side. The tremendous dynamic forces at work uncoiled into the right-side tire, and it spun wildly, taking the wound-up drivetrain with it, dragging the engine itself up another 764 rpm above redline.

That excursion probably triggered the ECU’s rev limiter; either the limiter or some other factor cut motor power and the car began to decelerate. Good thing, as a one-wheel-drive setup at that speed would be hard to control.



It only pulled through most of Mile 4, but that was enough.
The two-run average was 213.411 mph, 10+ mph over the previous record in H/Blown Gas Altered.

Izzat a RedHat? Oh yes it is.

Roundabout

We’re circling Iceland on the Ring Road, and now, on a detour off Hiway 1 to an old fishing village, the secondary roads are narrow, free of guardrails, and rarely dry. In lesser-traveled or shady areas, only the center of the pavement is clear of ice and snow, with one wheel track either side of the centerline. After a local van passes us with alacrity, I see why the road has that pattern. When no one’s oncoming, the traffic drives in the middle, sharing those two wheel tracks in each direction. Lend a hand keeping the road open, brother!

The sun rose, slowly, for 90 minutes or so, being above the horizon finally at 11:30am. Zenith was roughly two hours later, with the mild disk 18 or 20 degrees above level. There’s still a noticeable vegetation difference between the north-facing and south-facing hillsides, even with the rather dim sun lamp this time of year. The shady patches along the road can preserve enough snow to make even the shared two-track plan insufficient to clear the pavement.

Our Dacia Duster is exhausting to drive in these conditions. Seems like it shouldn’t be …  It’s a compact four-door SUV with a torquey diesel and a manual six-speed transmission, not too tippy, equipped of course with vetrardekk (winter tyres). Feels like plenty of grip on brake tests, but despite these good qualities it’s nerve-wracking. Finally I realize why: the steering is absolutely numb. There’s no feedback from the tires at all. It’s shifted more work onto our visual systems, demanding that we scan far closer to the nose of the car than we’d normally have to. When you give it steering input, you’ve got to look to see what’s changed with your vector, you can’t feel it.

We’re not going to be friends, the Duster and I.

Iceland’s dramatic waterfalls are mostly dramatically frozen, like tall dancers paused with poise, waiting for a beat to pass. This interval will last several months though; might be better to say “a half a year”.  The black stone mountains reek of antiquity, and some have improbably steep slopes. There’s a hint of scree, or perhaps the altered reflectivity on the inverted Vs of landslide tracks has you assuming a pile of rock at the bottom of the runs. Truly, there aren’t piles; the slope almost looks carved, bottom to top, from something that doesn’t really erode.

I Have Been That Soldier

In the side lobby of the five-star Hotel Vincci Estrella del Mar (rates lower in the off season) is a well-equipped bar. We were sitting at a tall table, sipping resort drinks, when three women careened in from the pool room. Two young, the third less than fifty, all clinging to each other with one hand and carrying tall glasses—vases, almost—two-thirds filled with bright-colored libations.

The party temporarily foundered in the shoals near our table, but regained headway and one hailed us as they passed:

”She (indicating her mature companion) has a pencil sharpener in her bag!” “A pencil sharpener,” chorused the third. Other notes and observations came emphatically forth, and the whole reminded me of a flock of small birds on encountering a pool of fresh water.

Their route to the stairwell included several tacks and feints, as they responded to the buffeting of unseen winds.

The passage filled the side lobby with cheerful energy, and strangers smiled at each other. Into the lull the barman deposited a single, somewhat rueful word: “Tequila”

An Irish lady walking back from the bar shared, with a nod, “I have been that soldier.”

When Jarring Is The Norm

Running south and east from Seville, the road signs count down the kms to Algeciras, the teeming port city on the Mediterranean and, further along, to Malaga, the Coste del Sol vacation niche. But never listed nor hinted at is Gibraltar, “The Rock”, in British hands since way back.

Lacking the textual announcements, you might fear you’ll miss the turn; but you need not worry. Even in gray-skyed March, the drizzle and fading light can’t mask the monolith. It is its own announcement. Its undeniability clashes with the pointed refusal-to-acknowledge attitude of its human neighbors.

Algeciras is a whirl of commerce. The ships in dock, or laying close by, are pumping goods in and out of this corner of Spain (and hence, this corner of Europe) at a heavy pace. In layers out from the container cranes are warehouses, yards, distribution and breaking-down points, all manner of specialty shippers and businesses concerned with collecting enough freight to warrant a shipment, or in efficiently de-aggregating arriving pallets into a dozen or more sub streams of goods. The lights in the city burn all night.

Approaching the border with Gibraltar, on the Spanish side, condos and shops and the rest of a standard build-out for a C.d.S. beach resort town packs the landward side of the highway. Eventually, miles later, the twin portals of Spanish exit and British entrance are ten meters apart. Our Spanish agent is all business, with quick pointed questions and brisk stamps. The UK guy recognizes the US Passport from a distance, even closed, and passes us in with a wave.

Here it is, then, clinging to the side of a mountain, a compressed little slice of Britain. We saw some historic military installs, and some signs of purposeful modern stuff, but mostly it was just a discordant jutting-out of mushy peas and dinner coats and propriety in a countryside of nature and flavor and drama.

From the Referendum Steps, we can look up the hill, and see the Union Jack riding the breeze.

Prerequisites

Ever been in a project where, in order to do A, you must first do B; and to do B, you have to get C working; and to get C working, well: you need a lathe.

I have a lathe, classic American model, gift from a friend. Its status at my house for some years has been, “needs assembled”. And, since its original power source was a foot treadle, it also needed some fabrication and wiring to fit an electric motor as the power source. The required materiel was in the same set of boxes that held the main body of the lathe, and similarly, “needed asssembly”.

It happens that the motor expects three-phase 208V, which would have ruled it out at my house (which has only single-phase 240V), save that another box held a “variable frequency drive / inverter”.

After a lot of learning, I got this today:

Speedweek 2020: The Comeuppance

Run Data Here

After 2018’s Red Hat triumph, we laid off for a year to see how our feelings vis-a-vis Bonneville racing developed. Would we be sated by that odyssey? Would we be anxious to return? Would the team take up iron-butt motorcycling instead?

Turns out that Salt Fever is not so easily cured. The team chatter about ‘trying to raise the Blown Gas Coupe record‘ started near the end of 2019. Here’s what we were thinking: this car ran 200+ on its last four outings, and nothing the motor said or did suggested that it’d been hurt by those record passes; if we just changed out some bodywork, Pickle would fit into another class, with a record just over 175mph. Shouldn’t it be easy to crank that up?Isn’t its mere existence at that level, in fact, a demand that it be raised?

In early 2020, a critical mass of interest formed, and work started. Pickle’d been resting in the Car Palace since it was cleaned up on our return in 2018, but now it was pulled out of hibernation and went on the lift. There was a bit of corrosion on the underbelly… then we found the frozen brake calipers… then found the immobile suspension… then noticed the funny way the turbo spun. Hmm. It doesn’t like sitting around, does it?

Another major challenge was that the engine control unit (ECU) and its complete harness had been removed. These components had been lent to Pickle for the 2018 meet, and were returned to the owners after. We got a duplicate ECU and harness, but figuring out where all the connectors and power leads went consumed several days. And one ECU output, for the tachometer, stubbornly refused to talk to the dash-mounted instrument, or at least it didn’t move the needle. We thought we’d keep trying when we had time…

Boom! It was August, and Speed Week was here. We packed a bunch of tools and the whole team, and went to the salt.

Pickle heads for the trailer.

Car #8600, the Flying Pickle, arrived Saturday morning and we set up pits east of Tech Inspection. Covid has changed the workflow on the salt, and the TechInspector (1) now comes to your pit as opposed to the car going to Tech Inspection. Formerly, there were three or four inspectors focused on each car as it came through, but now (having to account for travel out to various pits), there’s only one inspector.

We made a run on Saturday afternoon, but it was quite slow – around 165mph. That was a bit puzzling because this same motor/car combination ran over 200mph on its last outing. We turned to our old friend, ‘data’, to look for clues for the slowness… but found that both data collection systems had had problems on that Saturday run. The cause of those faults? Corrosion in electrical connectors. What they did tell us was that the driver was shifting early, and he admitted as much: “Without a tach, it is really hard to tell how high you’re spinning it. You have to realize how violent the experience is when the motor hits its sweet spot.” Hmmm… guess we better make the tach work.

Sunday we’d corrected the tach issue, and fixed the data collection problems, but we still weren’t reaching speeds we expected. Pickle went around 177mph. The data said that turbo boost fell off after the shift to fifth gear, and the car barely gained speed thereafter. It looked to us like the rpms in fifth gear were just slightly below the level where the turbocharger ‘takes over’, pushing more and more air into the engine and then feeding off the exhaust from that bigger meal. Turbochargers are self-reinforcing in that way, and require pressure relief valves in the exhaust plumbing to reduce the feedback effect. Otherwise the cycle continues ‘until a mechanical limit is reached’.

Sunday’s speed was still enough to qualify for a record attempt (barely), so the car went to the impound area for a designated work period and a ‘record run’ the following morning. While we were prepping systems in Impound, though, a gaggle of Tech Inspectors came over and told us the roof rails on the car were out of specification, and disqualified our run. I suspect that the issue would have been caught had the normal Tech Inspection routine been in place.

We towed Pickle out of impound, and removed the errant roof rails in our pits. Monday morning we made a small adjustment to the fueling in the rpm band corresponding to the rpm after a gear shift, and had the driver hold fourth gear to 10,200 rpm — hoping to land high enough in fifth gear to let the turbo pull it up into the powerband.

Our speed of 176mph again qualified us for a record attempt the next morning, so we were back in impound Monday afternoon, racking our brains to figure out why we weren’t going faster. We’d also noticed that Pickle was becoming very hard to start. It would crank without firing, pop a little, then crank again. We tried various combinations of throttle opening, fuel pump on/off, … crossing our fingers … but the hard starting coupled with the lack of speed had us doubting our assumptions.

Tuesday we were at the end of the road at 6am, along with other teams whose vehicles would be making record attempts. The officials led us out to the Impound area for a brief work period, and TeamPickle had a little extra time before we had to go to the starting line. We thought we’d start the engine to warm it up (and to reduce our anxiety about it not starting at all).

Our working theory Tuesday morning was that ‘cranking speed’ (the crankshaft rotational speed that the starter motor imparts) was low, and that was the cause of the hard starting. Pickle carries a large 12V battery on-board for running pumps, and this is also used for the starter motor. To augment that, we clamped on a battery charger, and connected our push truck’s umbilical cord. We had amps and volts a’plenty.

Press the button! whirr whirr whirr pop whirr whirr whirr whirr pop whirr whirr whirr whirr… (repeats)

Now our anxiety was back twofold. What is causing this?! The deadline to leave Impound was imminent. With nothing to lose, we decided to try bump-starting Pickle during the tow to the starting line. Hey – it works on motorcycles… sometimes.

And it worked for us: the engine fired very quickly, and we let it run during the tow to the start line. (We noticed on Thursday a.m. that other teams do similar bump starts… but I’m getting ahead of myself.)

The record we were chasing was 176.393 m.p.h. Our speed on the qualifying run would be averaged with our speed on the ‘record’ run. Our qualifying speed was over the record by just a little bit, so we could set a new record if Pickle could manage 175.267 m.p.h. plus. Pah – this car can go over 200 m.p.h. Should be easy.

We didn’t make it. The top speed was 174-ish. We towed back to the pits, out of ideas and frustrated.

Luckily, we had fresh eyes in the pits, a visiting couple that we know from rally racing in the Pacific Northwest. Steve is a professional mechanic, and he was able to re-set our tangled brains into verifying the basics of internal combustion:

  1. compression
  2. fuel
  3. spark

The compression gauge came out, and we checked all four cylinders. They read:
90# – 30# – 30# – 50#

Well, there’s your problem, Bob. This engine normally has approximately 160# across the board. That could explain the hard starting. But it also seemed really low… with those kind of numbers, how (we asked ourselves) is the car going 175m.p.h.? We kind of shrugged and pointed at the enormous turbocharger. Perhaps with enough boost, static compression matters less? This was blowing our minds, but the facts where there, right in front of us.

We went looking for the cause of the low compression. A shot of oil into the cylinders (to help the piston rings seal) didn’t change the numbers. We thought it likely we’d burned the edges off the exhaust valves, and we were losing seal there. A check of valve clearances on the exhaust, though, showed all eight in spec. The mystery deepens. Almost on a whim, we checked the valve clearances on the intake side, and then checked them again; because seven of eight were showing zero clearance. That would cause the valves to be slightly open in their ‘resting position’, and that would certainly reduce compression.

Did we bring the shims needed to set the clearance on the intake valves? No-sir-ree, we had not. That is why, if you were on Interstate 80 between Bonneville and Salt Lake City on Tuesday lunchtime, you’d have seen me around max legal speed heading to an open motorcycle shop for a shim kit.

I won’t describe in detail the hours and hours of work it required to get clearance on those intake valves, but we next made a run on Wednesday, in the late afternoon. Result: 177 m.p.h., qualifying speed, and we were back in Impound for the third time.

None of us had then an explanation for why the intake valve clearance disappeared, nor have we come up with one since. But there were other strange things happening with and strange noises emitting from the engine, and together they’re like a big red flag waving: You’ve been asking me to put out 3x normal power for many runs now, and I am… getting… tired.

We figured our chances of succeeding in our record run Thursday morning were less than 50-50 (the greater odds were on the combination of ‘running too slow’ and ‘blowing up violently’.)

So naturally… we turned up the boost.

Well, the motor will need a complete rebuild anyway; at least we’ll have a chance at setting a record. This was our rationale. And, before now, we’d always been afraid to touch the boost knob, which was still at the setting chosen by the engine tuners. So we felt both compelled and naughty when we twisted it a full turn.

At the starting line the next morning, we were part of a Spectrum Of Speed; the other lane held a 60cc moped which hoped to make 48 mph. Then the Pickle, hoping for 190 mph. And next to us, the recent king of wheel driven land speed, the Speed Demon streamliner run by Poteet & Main, which was shooting for 480 m.p.h.

In the foreground, Pickle; in the mid-field, a moped; and behind that moped, the 480mph streamliner Speed Demon.

All three of us set records.

  • The Pickle, just by the skin of its teeth. We ran 182mph with four pounds more boost than the day before. The average speed for our qualifying and record runs was a bit over 179mph.
  • The moped made 50mph.
  • The Speed Demon ran 480 and made it look very, very easy. Doesn’t take long to cover the five mile course when you’re over 300 at the two-mile mark. Our driver was outside the Pickle at Mile 6 when the streamliner driver(pilot?) pulled the ‘chute on the Speed Demon. Tom said he felt a shock wave in his chest.

    We’d completely exhausted ourselves during the week, and managed to raise the record in 1500cc Blown Gas Coupe by a measly 3mph. But it is the current record.

See Run Data Here

Speedweek 2020 Runs

Context available here.

MPH, 2020 vs. 2018

This is the GPS signal from the databox. We collect data more frequently now, so I had to ‘expand’ the 2018 trace to fit the timescale. We should try to use the same settings to make lining things up easier. 🙂

Note that the Nano seems to have died partway through the final run… all I had were zeros after that. You see the purple line just stop in the middle of its plateau. Also! You can see the lower gearing working, at least ’til the engine runs out of power.

MAP, 2020 vs. 2018

These are absolute manifold pressure values. They come from the databox, which is using a different style of MAP sensor than the ECU does. We should use the same damn sensor. 🙂 Can you tell which line is 2018?

Our cranked-up boost knob on Thursday (green line) was looking good at the beginning. We also lost that signal from the databox when the Nano stopped. You can see the ECU’s MAP numbers in the next graph, though. Not pretty.

ECU Map Vs. RPM, 2018-Final vs. 2020-Final

We changed the RPM at which logging starts, so the 2020 run starts ‘earlier’. We should try to use the same settings to make lining things up easier. 🙂

The two top lines are MAP, the two bottom lines are RPM. You can see the shift points in the MAP values of the 2018 line, but the 2020 MAP line is just … blah.

Timeslips

Run 1: Saturday, August 8th, 4:08 p.m.


Unpacked! Tech’d! Ran! but rpms were low, for good reason.

Run 2: Sunday, August 9th, 3:40 p.m.

Tach fixed, qualified! in two miles, #4 and #5. Went straight to Impound.

Speed seemed low, though. And the roof rails seemed high, according to the TechInspectors. The rails disqualified our run, and we went back to the pits for thinkin’.

The data showed a tiny speed trend upward throughout.

Run 3: Monday, August 10th, 1:08 p.m.

Qualified again, this time without roof rails.
Review of the data showed some good boost in the lower gears, but nuthin’ much happening in fourth or fifth gear. Spent some time talking about rev limits and shift points, and made a small tweak to the fueling around 8,800 rpm to try to help the engine get on the pipe.

A disturbing pattern emerged; mile four was only slightly faster than 3, and mile five was slower than 4.

Run 4: Tuesday, August 11th, 8:58 a.m.

We were in Impound from Monday’s run. We tried to start the engine to warm it up before towing out, but barely got a ‘pop’. In desperation, we decided to bump-start the car during the tow.

That worked, thank goodness. We were far back in the line at the start, as we’d delayed getting out of impound. With the engine running since the tow, the water temp was getting a bit high. We shut off the engine, figuring that we could bump-start it again at the line if necessary. But, warm now, the engine restarted when it needed to.

The run only went through Mile 4 ’cause that was the mile in which we qualified Monday. However, it was too slow to set a record.

Run 5: Wednesday, August 12th, 4:35 p.m.

After six or so attempts to get the intake valve clearances set, we had reasonable compression in the motor. Everything else was ready, and mile #4 qualified!

The overall pattern, though, was the same as the previous days; speed peaked in mile four, then slowed down thereafter. Checked the compression in Impound, and it was about the same as before the run. Where is the speed?

Found water on the floor of the cabin, and identified a crack in the coolant water tank behind the driver. N.B. epoxy sets up quick when the outside temp is near 100F.

Run 6: Thursday, August 13th, 8:04 a.m.



We were in Impound from Wednesday’s run. The water tank patch held overnight. Just before we towed out, Tom gave the Boost Control knob one full twist in the ‘+’ direction.  Later the ECU data from the MAP said boost was approximately 4psi higher than it had been.

We didn’t have to bump-start the car (though we feared we would).

The gear ‘slip/catch’ which had been present in 2nd gear now appeared in 1st gear as well. The car had good speed at the 2 1/4 mark, but struggled so much that the driver felt it hadn’t made the record; he was surprised to hear it worked.

The run only went through Mile 4 ’cause that was the mile in which we qualified Wednesday. Record set!

What A Long, Strange Trip It’s Been

All moments of life are colored by our emotions. None of us, in sensing – in seeing – is a neutral slate upon which experience is writ. We bring to every event a pre-setting, a state of ourselves; and what we feel in the offing is the combination of that state and the actual sensations of the event. This is what makes the anticipated kiss sweeter, the apprehended danger the more frightening, and the overdue respite more satisfying.

The Flying Pickle, Bonneville Speed Week 2018

Since Pickle first started trying to run 200 miles an hour, five years have passed. Most recently, in 2017, with a fresh motor and a ‘hot’ tune, we spent a day and a half driving to the Bonneville Salt Flats, only to find that the car’s ECU settings weren’t suited for the conditions, and the car made no more than 142 miles per hour. Our drive home was full of self-recrimination and regret.

This year we had a detailed plan. The tuning issue had been addressed with a session on the chassis dynometer. For everything else, we organized a series of work days, one a month, from March through July. We added sensors, produced logistical aids like towbars and a detachable muffler, and tried to validate that the car’s mechanical components were ready for 200 miles an hour. But it’s almost impossible to ‘test’ a land speed car… one needs many miles of road, with wide-open throttle, to reveal the real issues.

By the final work day, we were running short on things to do. We began talking about “What extra body parts should we bring to run in a second competition class after we break the record we’re targeting?” Oh, we were confident.

Since we were ahead of schedule, we left one day early, to reach the salt on Sunday, the second day of SpeedWeek. We wouldn’t be able to run Sunday, but we expected to do so on Monday. My imagination had us qualifying for the 200 mph record Monday afternoon, making the record run early the following morning, and thus being able to attend the RedHat (200mph Club) banquet scheduled for Wednesday night. I brought a suitcase full of dress shirts, because I thought we’d have time to kill between what promised to be one fantastic run after another.

Monday
No problems on the 11 hour drive from Battleground yesterday. We set up our pit and went over to register. Quite a few folks down there know the Pickle, and the registrar arranged to give us a cheaper pre-paid entry from a team that didn’t make it. A crew of safety inspectors checked the car over, and gave it thumbs up. We headed to the starting line.

Unlike 2017, when we queued at least four hours for each run, this time we waited perhaps half an hour. We barely had time to warm the motor up. We pushed Pickle off the line, and at around 50 miles an hour the car pulled away… not running completely cleanly, but obviously better than 2017. But as the push truck raced down course on the Return Road, the radio told us that the Pickle was already pulled over, barely past Mile Two.

We reached the car quickly. The driver told us there’d been a terrible noise from under the hood, and then the motor revved freely, with no drive to the wheels. He thought the car had thrown its chain. This felt distressingly familiar.

The chain drive system on the car is its Achilles’ heel; but what do you expect when you’re putting three times the normal power through it? One task on an early work day was ‘check the the chain drive system’, but at that time, all looked well. We saw no need for disturbing it, and besides, we didn’t see any obvious design improvements to make. The chain drive was one of the few systems that we didn’t fortify before we went to Bonneville; now that neglect came home to roost.

In the pits, we raised and supported the car, and removed the belly pan. Bits of broken chain were lying on the topside of the pan. Worse than that, we could see that the main sprocket, the one attached to the axle, was badly damaged. We set about removing the axle and sprocket for closer inspection. It is a tricky and annoying job, even in a shop, where you have a full toolbox and the car overhead on the lift. Now we were forced to do it lying flat on our backs, with limited maneuverability for tools and limited space for mechanics.

By 4 o’clock, we had the axle out. Then we saw the full extent of the damage.

We think the axle moved forward on one side in response to the pull of the motor. The chain then walked up the side of the sprocket, and as there’s very little slack in the system, the chain got real tight. The master link sheared off both pins in the end plate before failing completely. Then it was mostly a metal blender down there. Several teeth on the main sprocket were missing, or fractured. The chain was torn to pieces. The steel chain guard was mangled. Luckily, the engine sprocket was only lightly marred, and miraculously the engine cases showed no damage at all. (dang, that’s lucky. -ed)

There was no chance of continuing with that sprocket. And – we brought no spare, as working on the axle system was deemed ‘too difficult’ for the salt: why provision for actions that you cannot imagine taking? But now we had no choice but to work on it. If we couldn’t repair the chain drive system –and find a way to ensure that the axle would stay put under maximum power – we might as well go home; and nobody wanted to make another drive like 2017’s.

On the side of the sprocket was a manufacturer’s mark; not a part number, just a brand. An Internet search revealed that their factory was in Utah, somewhat south of Salt Lake City. (dang, that’s lucky. -ed) We found their phone number and called. Explaining our situation, we asked if they had a record of the sprocket, but they did not. The owner suggested that we measure our sprocket, pass those measurements to him, and they would do whatever it took to build a sprocket, and get it to us by mail by Wednesday.

But we were suddenly very conscious of time. Kicked off the salt at 8 PM, we returned to our casino/hotel and worked on a more expedient plan.

Tuesday
We dispatched two members of our team, at 4 AM, to drive to Richfield, Utah, and be at the sprocket-makers‘ shop when they opened. The rest of us headed out to start repairs and work on a more secure mounting system for the axle to resist the 400 hp of the motor.

By Tuesday midday the remote team had returned with a replacement sprocket. The rest of the day, we worked painstakingly to install the axle shaft, chain, and our one spare crush-fit master link for the chain. Conditions were ‘normal’ on the Salt in August, which is to say abnormal for most every other place on Earth. Blinding sun, a dearth of humidity, an occasional breeze bringing only parched air.

Under the car, we rotated shifts of workers. It went on all day. We left the salt Tuesday evening, not yet ready to run.

Wednesday
At daybreak, we headed back out. We’d try to implement our best idea for positively locating the axle. Part of this involved mechanical interference, part of it involved travel–limiting shims, and part of it involved assembling the main supporting members with prodigious torque on their fasteners. Space is very limited in the drivetrain area, and none of our tools was a perfect choice for leverage. We put two mechanics on the wrench simultaneously, one fore and one aft. Fingertips straining, proceeding in phases, we tightened the fasteners to the limit of our paired power.

While Pickle was still on jackstands, we test-ran the motor, then re-checked the drivetrain. The chain had loosened very slightly, so we took pains to readjust it. Then the belly pan went on, and we towed back to the start line.

Again our wait was short, and we pushed off within 30 minutes. This time she made a longer run, pulling well ahead and out of sight.

Over the radio, the timer read off the speed: 195mph in Mile Three! That’s 20mph faster than Pickle’s ever done before! The fourth mile was slower, though, and the driver pulled off before Five. This suggested another failure.

Audio – WednesdayRun

There were two failures. Our driver said the motor’d ‘gone soft’ around the Mile Four mark, and then shortly after, the car developed a strong pull to the right. He cut the run early. We towed back to the pits, and Pickle went back up on jackstands. Before long the cause of the pulling was obvious: the outer CV joint on the left halfshaft was completely destroyed. Blackened, scarred parts were falling out of the CV cup. With that CV joint in pieces, the power axle had no connection to the left front wheel; and without both wheels taking the power, the car was undriveable.

One positive note was that the sprocket system was intact, and looked to be operating as intended.

But again the day was winding down, and again the parts situation was dire. Sprockets are, in some sense, simple. A generalized factory can produce a wide range of them. Simplicity was what let our sprocket supplier make replacements while we waited. But the destroyed outer CV joint was a part built in 1964, in Sweden, from drawings and by machines long since retired. The relative obscurity of the SAAB 96 meant, also, that normal auto parts suppliers would not stock remanufactured units. We scoured the Internet again, and found one possible shop in Utah that might –might– have the vintage bit, but they weren’t answering the phone. It was getting late. The ‘lazy days of SpeedWeek’ had yet to materialize.

Without a CV joint, we were dead in the water.

Then someone hit on the solution: in Portland is a shop that (I daresay) specializes in SAAB 96s, and we had the owner’s personal cell phone number. While driving off the salt, we called him, and he was immediately on board. Yes, he had spare CV joints ready-to-go; yes, he had a special tool needed to install them; yes, he could create a video demonstrating the use of the tool for the tricky bits; and yes, he would dispatch his assistant to FedEx to overnight the parts and tool to us. The assistant called from the shipper, and we selected the best combination of delivery time and distance for us to drive. (dang, that’s lucky. -ed)

It was the best plan we had, and could perhaps work; but I deny 100% that any of us were ‘hopeful’ at that point.

And what about the motor softness? Had we started to cook some internal engine part, like an exhaust valve, or perhaps the turbocharger itself? That night in the hotel, we reviewed all our data, and tentatively diagnosed the problem as a displaced boost sensor hose (best case) or a failed sensor, or a split manifold, if we were less lucky.

Thursday
It felt like a repeat of Tuesday… two members drove toward the rising sun, east to Salt Lake City, aiming to reach FedEx at 9am and retrieve the package. The rest of the team hit the salt early to disassemble the broken joint from the wheel, and get ready to install the replacement. By noon, the parts were in the pits, and assembly commenced.

The fragility of the drive system under the increased power load demanded meticulous technique; things would barely hold together if everything was done perfectly – if anything wasn’t, it’s scrap time. But SpeedWeek was leaking away; Thursday’s qualifying runs must be backed up Friday morning; and any qualifying runs on Friday have to happen before 11am. Our cushion, our window for qualifying, was shrinking. So we had to rush, but we could not rush.

There was a grim intensity in the work area.

A displaced boost sensor hose was found, and fixed. (dang, that’s lucky. -ed) The CV joint was on. No time now to test the system, we settled for listening for bad noises while towing the car to the starting line. There were none, just a smooth whirrr on the way. Again we waited but a short time for our run. The driver babied the car off the start, and the pushbar was hard against Pickle ’til 80mph. Then Pickle was away, accelerating strongly, and before we lost sight of her, a clear salt roostertail could be seen – the sign of good speed.

She went 205mph through Mile Five, 3mph better than the existing record.

Audio – Thursday Qualify

We’d qualified for a run on the record the next morning; ’til then, we’d be confined to Impound. We towed in, finally, first time of the week, and spent a few hours charging batteries, refilling fluids, and adjusting the chain. When our allowed work-time was up, we drove off the salt in a mix of excitement and terror. This had been the first run of the week without a serious drivetrain failure. Would our ‘improved’ axle mounts hold up for another 200+ mph pass tomorrow?

Doubt is like the sea; it’s always there, and when it rises it may overwhelm thee.

Friday
We were at the edge of the salt in full darkness, part of a line of competitors who were likewise facing Record Runs. Around 6am the officials led us all out to Impound, and we warmed her engine, then hooked up to tow Pickle to the start.

We wanted to just face whatever would happen, and other folks were delaying, so we jumped ahead in line at their urging, and we were next.

Our fourth run of the week. The starting line checklist is more familiar now, check and double-check the harness and hood locks, get 100lbs of ice into the intercooler, pull the safety pins out of the parachute and halon fire extinguishers, and … ready to push.

Pickle’s motor, running raspy below 8500rpm, cracks and snaps as the big Chevy push truck leans into the work. By 45mph Pickle’s ready, spinning both fronts as it pulls away from us. We dive off the track for the Return Road, chasing her on a parallel track toward Mile Five, and Pickle’s flying, roostertail up, receding from our vision, out of sight in moments.

The timer reads the splits of the measured miles:
Mile Two 173 … Mile Three 195 … Mile Four 208 …Mile Five 209 mph
cheering in the push truck


Audio – Friday Record 1

Throw the chute in the trunk, pin the fire bottles, let’s go to Technical Inspection and get this thing certified.

Knowing that one element required is an engine measurement, we swing by our pits to get a spark plug socket to enable that measurement. We approach Tech Inspection, then, from the pit side, not from the Return Road. Triumphantly, we pull up to the station; and then in two sentences our joy is shattered. We’ve violated a basic rule by leaving the Return Road. Our detour to the pits is disqualifying. An appeal is made, other evidence of our innocence offered, but to no avail: our record attempt is null and void.

The air seemed hollow. Our energy drained away, and self-consoling rationales began forming in our minds. I doubt any of the team believed that we had the necessary time to re-qualify by 11am, nor believed that the patched-up drivetrain could handle two more passes at record-breaking speed.

But bystanders — plus the Tech Inspectors themselves — thought otherwise. They encouraged us. One spoke of another team, normally requiring four hours of maintenance between runs, who this morning had no choice but to attempt a two-hour turnaround. We had never prepared our car in less than three hours … it seemed hopeless.

We feel wrung out, like a toothpaste tube that’s empty.
Or is there one more ribbon in there? Perhaps we should try.

In the pits, we renewed fluids and fuel, partly charged the batteries, ignored the chain, packed the chute, and made it to the starting line. We’d have to run at least 203mph to be granted a record attempt. The motor was still warm, which shortened our preparation. The starting official was gracious and positive. We ran the checklist by the book, pins and belts and PUSH OFF!

Still raspy, Pickle rode the Chevy’s pushbar ’til 50mph, then surged away. The announcer didn’t understand why we were so quickly running again, and dithered on the radio… Meanwhile, Pickle’s got a roostertail, go baby go go go.

Through Mile Five, pulling strong, 206mph … a qualifying speed.

Audio – Friday Qualify

Now down at the end of the course, driver’s already stowed the ‘chute in the trunk, we have little time to waste. Driver says the car ran straight and strong and true. Up the Return Road and into the Impound Area, directly, with no deviations. Now we must again turn this car, get it ready for another pass in a couple hours.

The generator roars, powering the battery charger. We jack her up and pull the belly pan. Chain’s just slightly loose, one 32nd of a turn on the adjustment bolt. Fill the tank with A8-D, a $30/gallon racing gasoline that smells like … I dunno, but it smells powerful. Our turbo boost line is still secure. The datalogs say all systems are go.

The sun is positively blazing, throwing sharp edged dark shadows. Any shade or shielding is a godsend. Re-pack the chute, leads and lines stretched out on the white crust of impound. Can we look at…? No, we are out of time, and must run as we are.

A handful of qualified cars line up for the tow to the start. The course will close in an hour, the end of Speed Week.

At the line, the remaining spectators gaggle up, pulling for our chances, smiling at the gamble. Perhaps they don’t know it’s a gamble, they don’t know what we know, now, about pillow block bearings and CV joints and the special swaging it takes for a 530XWV2 chain’s master link; they don’t know about 2017’s humiliating 142mph runs. They don’t know about 2013’s burned valve, 2014’s rain-out of the whole meet, the poor salt of 2015, the chagrin of our disqualification five hours ago. We feel these things, and they have us totally engaged.

Push truck’s behind and touching, electrical umbilical’s plugged in. Pickle starts and is warming up. Checklist says pull the fire bottle pins out, parachute pin out, pour in the intercooler ice, get the cameras running. Driver’s inch-thick fireproof suit is fastened, seven-point harness rigged, window net up; pull out the auxiliary muffler. rummm rummm rummm goes to RUMP RUMP RUMP. Ready to start.

The official gives us the course.

The Chevy push truck has a 496 cubic inch V8, and we pull off the line smoothly then I bury the throttle. Pickle’s riding the pushbar, pointed at the horizon … starting now to sound more alive, drone turning to a howl as she rips away from the truck and is on her own.

The crew is silent as we hurtle down the Return Road chasing Pickle. The announcer’s been clued in to our plight, though he avoids mention of our rule violation, and he’s keenly tracking the timing numbers. There’s a delay while he calculates the average velocity, then he delivers the result: 207.153 mph, a new land speed record in 1500cc Blown Fuel Altered.

Audio – Friday Record 2

In the push truck, we snap from silent to loudly giddy, amazed that we recovered from our disqualification, amazed that our field repairs held, amazed, really, that the serious breakages we had Monday and Wednesday were even repairable on the Salt. If we’d come down to Bonneville on our original schedule, we’d have run out of time. So many things that could have gone wrong … did not.

At the end of the course, there stands the driver. He has no speedometer, but he does have a big tachometer, and he knew if it made 9800rpm through a mile that’d be enough. He knows.

We towed … where? Directly to Tech Inspection. Directly.

The motor size was verified and the record, certified. We were the last car to make a run at Speed Week 2018.
